Multi‑Specification Food‑Safe Beverage CO₂ Aluminum Cylinder
| Specially designed for beverage‑equipment OEMs, food‑gas fillers and cross‑border beverage‑goods wholesalers
Provide reliable and lightweight food‑grade carbon‑dioxide storage solutions for beverage‑equipment OEMs, food‑gas fillers and cross‑border beverage‑goods wholesalers. Solve the problems you face in scenarios such as household sparkling‑water appliance matching, commercial beverage carbonation and bulk food‑gas refilling operations where inferior inner treatment may cause gas contamination, and uncompleted pressure inspections bring hidden risks for repeated refilling cycles. Holding ISO 7866 and DOT‑3AL international certifications, it adopts strict food‑grade inner cleaning treatment and undergoes 100% full‑batch hydraulic pressure testing to deliver pure, safe carbon‑dioxide output for beverage applications, it supports bulk purchasing and OEM customization of cylinder colors, institutional logos and packaging.
Safety and Compliance
Each gas cylinder undergoes 100% water pressure testing, ultrasonic flaw detection and air tightness testing, and is accompanied by a traceable third-party certification report to ensure absolute safety.
Lightweight design
Compared with traditional gas cylinders, the weight is reduced by 30% to 40%, significantly lowering logistics costs and the operational load on workers.
Deep customization service
Supports OEM/ODM based on your filling gas, production line interface, and brand logo, including all-round customization in color, valves, size and packaging.
One-stop support
We offer full-cycle services ranging from technical selection consultation, compliance guidance to after-sales maintenance. Our professional engineering team is your strong backing.
| Drawing No. | Outside Diameter | Water Capacity | Length | Weight | Service Pressure | Test Pressure | Specification | ||||
| mm | in | liters | lbs | mm | in | kgs | lbs | bar/psi | bar/psi | ||
| MS-111-250-H-01 (1.9~4.6)L |
111 | 4.37 | 1.9 | 4.19 | 335.5 | 13.21 | 2.3 | 5.07 | 166.6/2415 | 250/3625 | TPED |
| 2.97 | 6.55 | 473 | 18.62 | 3.1 | 6.83 | ||||||
| 4.6 | 10.14 | 695 | 27.36 | 4.4 | 9.7 | ||||||
| MS-140-15-H-01 (0.3~0.9)L |
140 | 5.51 | 3 | 6.61 | 339 | 13.35 | 3.7 | 8.16 | 150/2175 | 225/3263 | GB/T11640 |
| 4 | 8.82 | 420 | 16.54 | 4.5 | 9.92 | ||||||
| 5 | 11.02 | 502 | 19.76 | 5.1 | 11.24 | ||||||
| 6 | 13.23 | 585 | 23.03 | 5.8 | 12.79 | ||||||
| 7 | 15.43 | 665 | 26.18 | 6.5 | 14.33 | ||||||
| 8 | 17.64 | 745 | 29.33 | 7.2 | 15.87 | ||||||
Material: High-quality aluminum alloy 6061-T6
Stamp markings: According to standards, additional markings are available upon request;
Surface treatment: brushed body;
Threads: M18x1.5, 17E, other threads available on request;
Valve: Tr21x4
Other Customization Options: Logos, Graphics, Packaging, Accessories (Nasal Cannula,
Oxygen Regulators, Cylinder carts);


OEM/ODM customization capability - integrating products into your brand and system
Our customized services cover four major dimensions
• Customized specifications: Volume, diameter, height, valve opening type - within the safety standard range, adjust as needed
• Customized appearance: Bottle body color, shoulder color matching, enterprise LOGO, product label - Let the gas cylinder become your mobile billboard
• Customized identification: Laser engraving, screen printing, permanent coding - achieving full life cycle traceability management
• Customized packaging: Exclusive packaging solutions, pallet specifications, and shipping mark designs - tailored to your warehousing and logistics systems
From sample confirmation to batch delivery, we offer one-on-one dedicated account manager coordination to ensure that every customized detail is precisely implemented.


Three major application scenarios for Multi‑Specification Food‑Safe Beverage CO₂ Aluminum Cylinder
Scene One: Household Sparkling‑water Appliance Matching
For consumer‑grade sparkling‑water product development operated by beverage‑equipment OEMs, inferior inner treatment may cause gas contamination, and uncompleted pressure inspections bring hidden risks for repeated refilling cycles. Poor internal processing may generate impurities which ruin beverage taste; insufficient pressure testing raises potential safety hazards and triggers product return risks for appliance brands. Multi‑Specification Food‑Safe Beverage CO₂ Aluminum Cylinder adopts strict food‑grade inner cleaning treatment and undergoes 100% full‑batch hydraulic pressure testing to deliver pure, safe carbon‑dioxide output for beverage applications. Light‑weight aluminum build facilitates daily handling for end‑users. Uniform product specifications simplify batch inventory management for cross‑border beverage‑goods wholesalers, and custom logo printing supports branded bundled sales of complete sparkling‑water retail kits.
Scene Two: Commercial Beverage Carbonation
When deploying CO₂ gas‑source hardware for cafe and beverage‑shop carbonated‑drink production by food‑gas fillers, inferior inner treatment may cause gas contamination, and uncompleted pressure inspections bring hidden risks for repeated refilling cycles. Frequent cylinder replacement in high‑traffic catering venues increases manual workload; unqualified cylinders create food‑safety threats for commercial beverage products. Multi‑Specification Food‑Safe Beverage CO₂ Aluminum Cylinder features professional food‑grade inner cleaning plus full‑batch hydraulic‑pressure inspection to guarantee clean and secure beverage‑grade gas supply. Seamless 6061‑T6 aluminum‑alloy main body adapts to repeated refilling and frequent venue transfer. Stable batch‑to‑batch quality enables beverage‑equipment OEMs to supply food‑safe beverage gas‑storage hardware, and flexible MOQ supports B‑end partners for market trial stocking.
Scene Three: Bulk Food‑gas Refilling Operations
Large‑scale food‑gas refilling and circulation projects demand contamination‑free, safety‑qualified CO₂ gas‑source hardware. Inferior inner treatment may cause gas contamination, and uncompleted pressure inspections bring hidden risks for repeated refilling cycles. Substandard cylinders pollute bulk refilled gas products; lack of pressure‑test records creates customs‑clearance barriers for cross‑border shipment. Multi‑Specification Food‑Safe Beverage CO₂ Aluminum Cylinder leverages rigorous food‑grade inner cleaning craft together with 100% hydraulic‑pressure testing to maintain pure gas quality and cyclic‑usage safety. Diversified water‑capacity selections satisfy varied bulk food‑gas refilling configuration demands. Full set of certification documents support commodity compliance inspection for B‑end purchasers. OEM options help partners build comprehensive beverage‑gas supporting‑equipment portfolios.

Full-process support from concept to mass production: From drawing review, prototype making to mass production and quality inspection, we offer one-stop services, significantly shortening your product launch cycle.
Flexible cooperation based on demand: Whether it's a small-batch trial order or a long-term large-scale framework purchase, we can offer competitive tiered pricing and stable inventory planning.
Cross-industry application expert: Our gas cylinder solutions have been successfully applied in fire-fighting equipment, medical devices, diving equipment and the beverage industry. We are glad to apply our cross-industry experience to solve your specific challenges.
Regarding packaging
In order to deliver our products to you in the condition in which they were sent, we use strict, strong, efficient and environmentally friendly packaging methods.
Our standard packaging method for our products is to cover them with plastic bags, put them into cartons, then place the cartons on pallets and wrap them tightly with stretch film to ensure that the cylinders do not collide with each other during transportation. Other packaging methods can be provided upon request.


Certification system of Midstar
• U.S. market: DOT-3AL (U.S. Department of Transportation Standard for Aluminum Alloy Gas Cylinders)
• EU market: TPED /EU + PED /EU (Dual Directive compliance)
• International standard: ISO 7866 (Global Technical Benchmark for Gas Cylinder Industry)
• UK market: BS 5045-8 (UK National Standard)
• Chinese market: GB/T 11640 (National Recommended Standard of China)
All certifications are reviewed and issued by international authoritative institutions to ensure the authenticity and traceability of compliance documents.

Professional service commitment
We offer comprehensive support, not just products.
Bulk purchasing plan: Based on your annual purchasing volume, we offer tiered preferential prices and flexible delivery plans.
Customized services: Supports institutional customization of gas cylinder colors and markings, facilitating asset identification and management.
Training and Guidance: Provide training on product usage and safety regulations for your team.
After-sales service and Inspection: We offer regular safety inspection services for gas cylinders or assist in contacting qualified local inspection institutions.


Call to action
To the Procurement Managers of Institutions, if you are evaluating or updating equipment, we can provide you with:
Free sample experience: Test the lightness and reliability of the product in person.
Contact our B2B sales team immediately to get a personalized quotation and solution.
FAQs
Q: Is it safe to have carbon dioxide gas cylinders in my home?
A: CO2 cylinders are completely safe in your home. They are manufactured to strict safety specifications to protect our consumers and are safe at almost any altitude.
Q: Will my CO2 cylinder expire?
A: Although the gas in CO2 cylinders does not expire, our cylinders require a quality assurance check by a certain date, which can be found at the bottom of the cylinder. For best use, we recommend storing the cylinders at room temperature.
